CPCD30
SPECIFICATIONS
Rated load
Standard bucket capacity
Power
40KW
Descriptions
No-load maximum lifting height 4500 Free lifting height 160 Minimum turning radius (outer side) 2240 Mast tilt angle (front/rear) 6°/12° maximum lifting speed(Full-load/No-load) 485/505 maximum working speed(Full-load/No-load) 18/20 maximum gradeability(Full-load/No-load) 15/20 Forklift weight under standard no-load condition 4450 Tire no. (F/R) 2/2 Tire size (F) 28x9-15 Tire size (R) 6.50-10 Engine model XINCHAI C490 Power 40kw Other Optional Items Electronic Gear Shift Solid Tires Customized mast frame height/number of stage Customized fork length/width Dual Fuel LPG Converter High Position exhaust External Multi-Valve Connection Interchangeable Composite Counterweight
Technical Parameters
Model CPCD30 Power Diesel Rated lifting load 3000 Load center distance 500 Driving mode Seat driving Length 3930/2690 Width 1210 Height 2100 Fork size 1070*100*50 Wheelbase 1700 No-load maximum lifting height 110 No-load maximum lifting height 4500 Free lifting height 160 Minimum turning radius (outer side) 2240 Mast tilt angle (front/rear) 6°/12° maximum lifting speed(Full-load/No-load) 485/505 maximum working speed(Full-load/No-load) 18/20 maximum gradeability(Full-load/No-load) 15/20 Forklift weight under standard no-load condition 4200 Tire no. (F/R) 2/2 Tire size (F) 28x9-15 Tire size (R) 6.50-10 Engine model XINCHAI C490 Power 40kw
